Capacity: 5-250 lb, 22-1112 N, 2-113 Kg
Display units in pounds, newtons or kilograms (dip switch controlled)
Resolution: 0.1 lb
Accuracy: 0.5 % of full scale
Digital Display with Peak Hold
Backlit LCD Display with 0.56" High Digits
1" - 10" Per minute Selectable Rate of Pull in ten 1"/min increments
1/8"/min @ 1" - 5"/min
1/4"/min @ 6" - 10"/min
Auto Stop on Wire Break
Calibration Self-Test each time unit is switched ON
Auto Return to Start Position in Reset Mode
Factory Set Overload Protection
Versatile 15-Position Slotted Terminal Lower Grip (P/N 15-3087)
Self-Tightening Cam-Type Upper Grip (P/N 15-3040)
Easy Setup, Operation and Grip Change
Compact Size
AC Line Filter
115 VAC 50/60Hz Power with .3 Amp Fuse
Adjustable Front Feet for Optimum Test Position
