Control Loading Systems

Higher Fidelity in Control Force Simulation

Decades of experience and more than 4,000 control loading channels in the field mean that we're your trusted partner for both military and commercial control loading systems.

Moog control loading solutions range from basic flight training to high fidelity full flight simulation that meet the highest level of certification from the JAA, FAA and military equivalents worldwide. Typical set-ups include a base frame, interconnecting linkages, replica controls and integrated control loading hardware and software.

Unique Features

Our unique model-follower force-loop technology provides the technical foundation for all our systems. Combined with highly responsive electric actuators and sophisticated software models, this technology provides the highest fidelity control loading anywhere.

All actuators are based on brushless permanent magnet servomotors and digital control electronics for smooth, reliable performance.

We offer an extensive range of high-performance linear and rotary actuators designed for the specific application needs of primary and secondary controls. These include:

• Electric Rotary Control Loaders High Dynamic are based on high torque servo motors in a direct-drive set-up and capable of generating output torque of up to 200 Nm continuously for high-fidelity requirements.

• Electric Rotary Control Loaders Medium Dynamic for secondary controls and primary controls. They provide a medium torque and medium velocity

• Electric Linear Control Loaders for heavily-loaded primary controls

Advantages

Our control loading products offer the following advantages:

• Highest fidelity of control loading available

• Amplifiers and computers included

• Modular design and broad range of systems to meet any customer need

• High-quality actuators and digital control electronics for smooth, reliable performance

• Designed to meet the world's highest levels of certification from the JAA, FAA and military equivalents worldwide
