Number of Spindles

2, 3 or 4 Spindles

Power Supply

220 Vac, single phase

Motor

Kw 1.5/2 HP, 220 Vac, single phase

Winding Speed

0 - 6000 rpm or constant linear speed

Jog Speed

50 rpm

Bobbin Dimensions

125mm x 167 mm (5in. x 6.50 in.)

Braid Material

Wire, copper, aluminum, soft steel and textile

Wire Size

25 to 45 AWG

Motor

2 HP

Traverse

Infinitely adjustable

Weight (2,3,4 spindle)

200 Kg (440 lbs.), 210 Kg (470 lbs.), 225 Kg (500 lbs.)

Dimensions (2 spindle)

800 W x 810 D x 1100 mm H (31.5 W x 32 D x 43.5 in H)

Dimensions (3 spindle)

1150 W x 810 D x 1100 mm H (45.5 W x 32 D x 43.5 in H)

Dimensions (4 spindle)

1500 W x 810 D x 1100 mm H (59 W x 32 D x 43.5 in H)

Miscellaneous

Alpha-numeric messaging for faults and settings

Emergency Stop

Electronic counting of traverse for predetermined bobbin size
